Intel Desktop Board D955XBK Technical Product Specification
62
2.7.2.2 Add-in Card Connectors
The board has the following add-in card connectors:
• PCI Express x16; one connector supporting simultaneous transfers up to 8 GBytes/sec
• Secondary PCI Express x16/x4 bus; one connector supporting simultaneous transfers up to
2 GBytes/sec
• PCI Express x1; one connector supporting simultaneous transfers up to 500 MBytes/sec
• PCI Conventional (rev 2.2 compliant) bus; three PCI Conventional bus add-in card connectors.
The SMBus is routed to PCI Conventional bus connector 2 only (ATX expansion slot 6). PCI
Conventional bus add-in cards with SMBus support can access sensor data and other
information residing on the Desktop Board.
Note the following considerations for the PCI Conventional bus connectors:
• All of the PCI Conventional bus connectors are bus master capable.
• SMBus signals are routed to PCI Conventional bus connector 2. This enables PCI
Conventional bus add-in boards with SMBus support to access sensor data on the Desktop
Board. The specific SMBus signals are as follows:
⎯ The SMBus clock line is connected to pin A40.
⎯ The SMBus data line is connected to pin A41.
2.7.2.3 Auxiliary Front Panel Power/Sleep LED Connector
Pins 1 and 3 of this connector duplicate the signals on pins 2 and 4 of the front panel connector.
Table 30. Auxiliary Front Panel Power/Sleep LED Connector
Pin Signal Name In/Out Description
1 HDR_BLNK_GRN Out Front panel green LED
2 Not connected
3 HDR_BLNK_YEL Out Front panel yellow LED
