Table 18.  ATAPI CD-ROM Connector (Optional)
Pin Signal Name
1  Left audio input from CD-ROM
2  CD audio differential ground
3  CD audio differential ground
4  Right audio input from CD-ROM

Table 19.  Front Panel Audio Connector
Pin Signal Name  Pin Signal Name
1  Port E [Port 1] Left Channel  2  Ground
3  Port E [Port 1] Right Channel  4  Presence# (dongle present)
5  Port F [Port 2] Right Channel  6  Port E [Port 1] Sense return
(jack detection)
7  Port E [Port 1] and Port F [Port 2]
Sense send (jack detection)
8 Key
9  Port F [Port 2] Left Channel  10  Port F [Port 2] Sense return
(jack detection)
#
INTEGRATOR’S NOTE
The front panel audio connector is colored yellow.
Table 20.  Front Chassis Fan and Rear Chassis
Fan Connectors
Pin Signal Name
1 Control
2  +12 V
3 Tach

Table 21.  Processor Fan Connector and
Auxiliary Rear Fan Connector
Pin Signal Name
1 Ground
2 +12 V
3 FAN_TACH
4 FAN_CONTROL
