Intel Desktop Board DH87MC Technical Product Specification
12
Table 1. Feature Summary (continued)
Peripheral
Interfaces
• USB 3.0 ports:
― Two USB 3.0 ports are implemented with stacked back panel connectors
― Two front panel USB 3.0 ports are implemented through one internal
connector
• USB 2.0 ports:
― Four ports are implemented with stacked back panel connectors
― Four front panel ports are implemented through two dual-port internal
connectors
― One single-port internal header for front panel cabling
― One port is reserved for the PCI Express Full-/Half-Mini Card slot
• Five Serial ATA (SATA) 6.0 Gb/s ports
Audio 10-channel (8 + 2) Intel High Definition Audio via the Realtek* ALC892 audio
codec
LAN Support
Gigabit (10/100/1000 Mb/s) LAN subsystem using the Intel
®
I217V Gigabit
Ethernet Controller
Expansion
Capabilities
• One PCI Express x16 3.0/2.x/1.x add-in card connector
• One PCI Express x16 3.0/2.x/1.x add-in card connector (x4 electrically)
• Two PCI Express x1 2.x/1.x add-in card connectors
• Three Conventional PCI bus add-in card connectors
• One PCI Express Full-/Half-Mini Card slot with support for mSATA
Intel
®
Visual BIOS
•
Intel
®
BIOS resident in SPI Flash device
• Support for Advanced Configuration and Power Interface (ACPI), Plug and Play,
and SMBIOS
Instantly Available
PC Technology
•
Support for PCI Express* Revision 3.0
• Suspend to RAM support
• Wake on PCI Express, LAN, front panel, Consumer Infrared (CIR), and
USB ports
Super I/O Control Nuvoton NCT6883D-T I/O controller for CIR and hardware management support
Hardware Monitor
Subsystem
• Hardware monitoring through the Nuvoton I/O controller
• Voltage sense to detect out of range power supply voltages
• Thermal sense to detect out of range thermal values
• Three fan headers
• Three fan sense inputs used to monitor fan activity
• Fan speed control
