Intel DH87MC User Manual

Technical Reference
43
Table 13 lists the component-side connectors and headers identified in Figure 9.
Table 13. Component-side Connectors and Headers Shown in Figure 9
Item/callout
from Figure 9 Description
A Conventional PCI add-in card connector
B Conventional PCI add-in card connector
C Conventional PCI add-in card connector
D PCI Express x16 add-in card connector (x4 electrically)
E Rear chassis fan header
F PCI Express x1 add-in card connector
G PCI Express x16 add-in card connector
H PCI Express x1 add-in card connector
I Processor core power connector (2 x 2)
J Processor fan header
K Front fan header
L Main power connector (2 x 12)
M Front panel USB 3.0 connector
N Chassis intrusion header
O SATA 6.0 Gb/s connectors
P Front panel header
Q Alternate front panel power/sleep LED header
R Front panel dual-port USB 2.0 connector
S Front panel dual-port USB 2.0 connector
T Front panel single-port USB 2.0 header
U PCI Express Full-/Half-Mini Card slot
V Consumer IR receiver (input) header
W Trusted Platform Module header
X S/PDIF out header
Y Front panel audio header

Intel DH87MC Specifications

General

Form Factor	Micro ATX
Chipset	Intel H87
Socket	LGA 1150
Memory Slots	4
Maximum Memory	32 GB
Memory Type	DDR3
PCI Express x16	1
SATA 6Gb/s	6
USB 3.0 Ports	4
USB 2.0 Ports	8
RAID Support	RAID 0, 1, 5, 10
Ethernet	Gigabit Ethernet
Video Ports	HDMI, DVI, VGA
PCI Express x1	2 x PCIe 2.0 x1
