Intel Desktop Board DH87MC Technical Product Specification
14
Table 2 lists the components identified in Figure 1.
Table 2. Components Shown in Figure 1
Item/callout
from Figure 1
Description
A Conventional PCI add-in card connector
B Conventional PCI add-in card connector
C Conventional PCI add-in card connector
D PCI Express x16 add-in card connector (x4 electrically)
E Rear chassis fan header
F PCI Express x1 add-in card connector
G Battery
H PCI Express x16 add-in card connector
I PCI Express x1 add-in card connector
J Piezoelectric speaker
K Back panel connectors
L Processor core power connector (2 x 2)
M LGA1150 processor socket
N Processor hot LED
O Processor fan header
P VR hot LED
Q DIMM 3 (Channel A DIMM 0)
R DIMM 1 (Channel A DIMM 1)
S DIMM 4 (Channel B DIMM 0)
T DIMM 2 (Channel B DIMM 1)
U Front fan header
V Main power connector (2 x 12)
W Front panel USB 3.0 connector
X Intel H87 Express Chipset
Y Chassis intrusion header
Z SATA 6.0 Gb/s connectors
AA Front panel header
BB Enhanced standby power LED
CC Alternate front panel power/sleep LED header
DD BIOS security jumper
EE
Power supervisor LED
FF Front panel dual-port USB 2.0 connector
GG Front panel dual-port USB 2.0 connector
HH Front panel single-port USB 2.0 header
II PCI Express Full-/Half-Mini Card slot
JJ Consumer IR receiver (input) header
KK Trusted Platform Module header
LL S/PDIF out header
MM Front panel audio header

Intel DH87MC Specifications

General

Form Factor	Micro ATX
Chipset	Intel H87
Socket	LGA 1150
Memory Slots	4
Maximum Memory	32 GB
Memory Type	DDR3
PCI Express x16	1
SATA 6Gb/s	6
USB 3.0 Ports	4
USB 2.0 Ports	8
RAID Support	RAID 0, 1, 5, 10
Ethernet	Gigabit Ethernet
Video Ports	HDMI, DVI, VGA
PCI Express x1	2 x PCIe 2.0 x1
