Intel Desktop Board DH87MC Technical Product Specification
20
1.4 Intel
®
H87 Express Chipset
Intel H87 Express Chipset with Direct Media Interface (DMI) interconnect provides
interfaces to the processor and USB, SATA, LPC, LAN, and PCI Express. The Intel H87
Express Chipset is a centralized controller for the board’s I/O paths.
For information about Refer to
The Intel H87 chipset
http://www.intel.com/products/desktop/chipsets/index.htm
Resources used by the chipset Chapter 2
1.4.1 Direct Media Interface (DMI)
Direct Media Interface (DMI) is the chip-to-chip connection between the processor and
the PCH. This high-speed interface integrates advanced priority-based servicing
allowing for concurrent traffic and true isochronous transfer capabilities.

Intel DH87MC Specifications

General

Form Factor	Micro ATX
Chipset	Intel H87
Socket	LGA 1150
Memory Slots	4
Maximum Memory	32 GB
Memory Type	DDR3
PCI Express x16	1
SATA 6Gb/s	6
USB 3.0 Ports	4
USB 2.0 Ports	8
RAID Support	RAID 0, 1, 5, 10
Ethernet	Gigabit Ethernet
Video Ports	HDMI, DVI, VGA
PCI Express x1	2 x PCIe 2.0 x1
