Intel DH87MC User Manual

iii
Board Identification Information
Basic Desktop Board DH87MC Identification Information
AA Revision BIOS Revision Notes
G74242-401 MCH8710H.86A.0043 1,2
Notes:
1. The AA number is found on a small label on the component side of the board.
2. The H87 chipset used on this AA revision consists of the following component:
Device Stepping S-Spec Numbers
Intel H87 Express Chipset C1 SR139
Errata
Current characterized errata, if any, are documented in a separate Specification
Update. See
http://www.intel.com/content/www/us/en/motherboards/desktop-
motherboards/motherboards.html?wapkw=desktop+boards for the latest
documentation.

Intel DH87MC Specifications

General

Form Factor	Micro ATX
Chipset	Intel H87
Socket	LGA 1150
Memory Slots	4
Maximum Memory	32 GB
Memory Type	DDR3
PCI Express x16	1
SATA 6Gb/s	6
USB 3.0 Ports	4
USB 2.0 Ports	8
RAID Support	RAID 0, 1, 5, 10
Ethernet	Gigabit Ethernet
Video Ports	HDMI, DVI, VGA
PCI Express x1	2 x PCIe 2.0 x1
