Intel DH87MC User Manual

Error Messages and Beep Codes
81
Table 46. Port 80h POST Codes (continued)
Port 80 Code Progress Code Enumeration
Removable Media
0xB8 Resetting removable media
0xB9 Disabling removable media
0xBA Detecting presence of a removable media (IDE, CDROM detection
etc.)
0xBB Enabling/configuring a removable media
DXE Core
0xE4 Entered DXE phase
BDS
0xE7 Waiting for user input
0xE8 Checking password
0xE9 Entering BIOS setup
0xEB Calling Legacy Option ROMs
Runtime Phase/EFI OS Boot
0xF8 EFI boot service ExitBootServices ( ) has been called
0xF9 EFI runtime service SetVirtualAddressMap ( ) has been called

Intel DH87MC Specifications

General

Form Factor	Micro ATX
Chipset	Intel H87
Socket	LGA 1150
Memory Slots	4
Maximum Memory	32 GB
Memory Type	DDR3
PCI Express x16	1
SATA 6Gb/s	6
USB 3.0 Ports	4
USB 2.0 Ports	8
RAID Support	RAID 0, 1, 5, 10
Ethernet	Gigabit Ethernet
Video Ports	HDMI, DVI, VGA
PCI Express x1	2 x PCIe 2.0 x1
