Intel DN2800MT Specification

13
1 Product Description
1.1 Overview
1.1.1 Feature Summary
Table 2 summarizes the major features of the board.
Table 2. Feature Summary
Form Factor
Mini-ITX (6.7 inches by 6.7 inches [170.18 millimeters by 170.18 millimeters])
Processor Fanlessly-cooled, soldered-down Dual-Core Intel
®
Atom™ Processor N2800 with
integrated graphics and integrated memory controller
Memory
•
Two 204-pin DDR3 SDRAM Small Outline Dual Inline Memory Module (SO-
DIMM) sockets
• Support for DDR3 800 MHz and DDR3 1066 MHz SO-DIMMs
Note: Higher speed SO-DIMMs supported at 1066 MHz if supported by the
memory module.
• Support for up to 4 GB of system memory on a single SO-DIMM (or two
2 GB SO-DIMMs)
Chipset
Intel
®
NM10 Express Chipset
Graphics
•
Integrated graphics:
― Digital displays (High Definition Multimedia Interface* (HDMI*))
― Analog displays (VGA)
― Internal flat panel displays:
 LVDS
 eDP (Embedded DisplayPort*)
• External graphics:
― One PCI Express 1.0a x1 graphics add-in card connector
Audio
• 2+2 Intel
®
High Definition (Intel
®
HD) audio via the Realtek* ALC888S audio
codec
― Analog stereo line-out (back panel jack)
― In-chassis stereo speakers support (3 W/3 Ω via internal header)
― S/PDIF digital audio output (internal header)
― DMIC digital microphone input (internal header)
― Analog line-in (back panel jack)
― Front panel Intel HD Audio/AC’97 headphones/mic support (internal
header)
• 8-channel (7.1) Intel High Definition Audio via the HDMI interface
continued
