Intel Desktop Board DN2800MT Technical Product Specification
58
Table 33. PCI Express Full-/Half-Mini Card Connector (continued)
Pin Signal Name Additional Signal Name
39 +3.3 V aux (mSATA) 3.3 V
40 GND
41 +3.3 V aux (mSATA) 3.3 V
42 LED_WWAN#
43 Reserved NC (mSATA indicator)
44 LED_WLAN#
45 Reserved (mSATA) Vendor
46 LED_WPAN#
47 Reserved (mSATA) Vendor
48 +1.5V
49 Reserved (mSATA) DA/DSS
50 GND
51 Reserved (mSATA) Presence Detection
52 +3.3 V aux
2.2.3.2 Add-in Card Connectors
The board has the following add-in card connectors:
• One PCI Express 1.0a x1 connector. The x1 interface supports simultaneous
transfer speeds up to 250 MB/s of peak bandwidth per lane, per direction, for up to
500 MB/s concurrent and bi-directional bandwidth.
• One PCI Express Half-Mini Card slot
• One PCI Express Full-/Half-Mini Card slot (removable stand-offs in full-length keep
out zone allows repurposing of Full-Mini Card slot into Half-Mini Card slot)
2.2.3.3 Power Supply Connectors
The board supports wide-range voltage input by either of the following power supply
types:
• External Power Supply – the board can be powered with an 8 - 19 VDC external
power supply though the DC jack on the back panel. This connector accepts dual-
barrel plugs with an inner diameter (ID) of 2.5 mm and an outer diameter (OD) of
5.5 mm, where the inner contact is +8 (±10%) through +19 (±10%) VDC and the
shell is GND. The maximum current rating for this connector is 8 A.
• Internal Power Supply – the board can alternatively be powered via the internal
1 x 2 power connector, where pin 1 is GND and pin 2 is +8 (±10%) through +19
(±10%) VDC. The maximum current rating for this connector is 10 A.
Table 34. Internal Power Supply Connector Pinout
Pin Signal Name
1 Ground
2 DC input: +8 (±10%) through +19 (±10%) VDC
