Technical Reference
71
2.6.2 Fan Header Current Capability
Table 40 lists the current capability of the fan header.
Table 40. Fan Header Current Capability
Fan Header Maximum Available Current
System fan 1.5 A
2.6.3 PCI Express* Add-in Card Considerations
The motherboard is designed to provide up to 10 W to the PCI Express x1 slot. The
total power consumption from add-in boards on this slot must not exceed this rating.
2.7 Thermal Considerations
CAUTION
For fanless operation, a chassis with adequate venting holes to enable fanless cooling
of all board- and system-level components is required.
CAUTION
Failure to ensure appropriate airflow may result in reduced performance of both the
processor and/or voltage regulator or, in some instances, damage to the board.
All responsibility for determining the adequacy of any thermal or system design
remains solely with the system integrator. Intel makes no warranties or
representations that merely following the instructions presented in this document will
result in a system with adequate thermal performance.
CAUTION
Ensure that the ambient and especially the internal chassis temperatures do not
exceed the board’s maximum operating temperatures. Failure to do so could cause
components to exceed their maximum case temperature and malfunction. For
information about the maximum operating temperatures, see the environmental
specifications in Section 2.9.
CAUTION
Ensure that proper airflow is maintained in the processor voltage regulator circuit.
Failure to do so may result in damage to the voltage regulator circuit. The processor
voltage regulator area (shown in Figure 23) can reach a temperature of up to 85
o
C in
an open chassis.
