Intel Desktop Board DN2800MT Technical Product Specification
22
1.5 Intel
®
NM10 Express Chipset
Intel NM10 Express Chipset with Direct Media Interface (DMI) interconnect provides
interfaces to the processor and the USB, SATA, LPC, LAN, and PCI Express interfaces.
The Intel NM10 Express Chipset is a centralized controller for the board’s I/O paths.
For information about Refer to
The Intel NM10 chipset http://www.intel.com/products/desktop/chipsets/index.htm
Resources used by the chipset Chapter 2
1.6 Graphics Subsystem
The board supports graphics through Intel Graphics Technology.
1.6.1 Integrated Graphics
The board supports integrated graphics through the Intel
®
Flexible Display Interface
(Intel
®
FDI) for processors with Intel Graphics Technology.
NOTE
The board can simultaneously support up to two of the three integrated graphics
interfaces: VGA, HDMI, and Flat Panel Display.
Flat Panel Display is supported by eDP and LVDS interfaces, however only one can be
used at a time.
1.6.1.1 Intel
®
High Definition (Intel
®
HD) Graphics
The Intel
®
GMA graphics controller features the following:
• 640 MHz core frequency
• Video
 Blu-ray* 2.0
 PAVP 1.1c
 HDCP 1.3
• Display
 Supports VGA displays up to 1920 x 1200 (WUXGA) at 60 Hz
 Supports HDMI displays up to 1920 x 1200 (WUXGA) at 60 Hz
 Supports eDP or LVDS internal flat panel displays up to 1920 x 1080 at 60 Hz
 Dual independent display support
For information about Refer to
Obtaining graphics software and utilities Section 1.2, page 19
