Intel Desktop Board DN2800MT Technical Product Specification

Table 27. System Fan Header

Pin Signal Name

1 Ground

2 +12 V (PWM controlled pulses)

3 Tach

Table 28. Flat Panel Voltage Selection Header

Pin Signal Name Description

1 Key No pin

2 3.3 V 3.3 V option (default)

3 12 V 12 V option

4 LCD_VCC Send voltage to connector

5 Key No pin

6 5 V 5 V option

Table 29. Backlight Inverter Voltage Selection Header

Pin Signal Name Description

1 Key No pin

2 5 V 5 V option

3 Vin Board input voltage option

4 BKLT_PWR Send voltage to connector

5 Key No pin

6 12 V 12 V option
