Intel Desktop Board DN2800MT Technical Product Specification
36
1.12.3 Thermal Monitoring
Figure 9 shows the locations of the thermal sensor and fan header.
Item Description
A System fan header
B Thermal diode, located on the processor die
Figure 9. Thermal Sensor and Fan Header
