Product Description
23
1.6.1.2 Video Memory Allocation
Intel
®
Dynamic Video Memory Technology (DVMT) is a method for dynamically
allocating system memory for use as graphics memory to balance 2D/3D graphics and
system performance. If your computer is configured to use DVMT, graphics memory is
allocated based on system requirements and application demands (up to the
configured maximum amount). When memory is no longer needed by an application,
the dynamically allocated portion of memory is returned to the operating system for
other uses.
1.6.1.3 High Definition Multimedia Interface* (HDMI*)
The HDMI port supports standard, enhanced, or high definition video, plus multi-
channel digital audio on a single cable. It is compatible with all ATSC and DVB HDTV
standards and supports eight full range channels at 24-bit/96 kHz audio. The
maximum supported resolution is 1920 x 1200 (WUXGA). The HDMI port is compliant
with the HDMI 1.3a specification.
Depending on the type of add-in card installed in the PCI Express x1 connector, the
HDMI port will behave as described in Table 6.
Table 6. HDMI Port Status Conditions
PCI Express x1 Connector Status HDMI Port Status
No add-in card installed Enabled
Non-video PCI Express x1 add-in card installed Enabled
Video PCI Express x1 add-in card installed Disabled
1.6.1.4 Analog Display (VGA)
The VGA port supports analog displays. The maximum supported resolution is 1920 x
1200 (WUXGA) at a 60 Hz refresh rate.
