Product Description
25
1.8 Legacy I/O Controller
The I/O controller provides the following features:
• One serial port header
• Serial IRQ interface compatible with serialized IRQ support for PCI systems
• Intelligent power management, including a programmable wake-up event interface
• PCI power management support
The BIOS Setup program provides configuration options for the I/O controller.
1.8.1 Serial Port
The board has one serial port header located on the component side of the board. The
serial port supports data transfers at speeds up to 115.2 kbits/sec with BIOS support.
For information about Refer to
The location of the serial port header Figure 10, page 50
The signal names of the serial port header Table 16, page 53
