Intel DQ45CB User Manual

Technical Reference
51
Table 11 lists the component-side connectors and headers identified in Figure 10.
Table 11. Component-side Connectors and Headers Shown in Figure 10
Item/callout
from Figure 10 Descri
ption
A Front panel audio header
B PCI Conventional bus add-in card connector
C PCI Express x1 connector
D PCI Express x16 connector
E PCI Express x1 connector
F Rear chassis fan connector
G Processor core power connector (2 X 2)
H Serial port header
I Processor fan header
J Main power connector (2 X 12)
K Front chassis fan header
L Chassis intrusion header
M Auxiliary front panel power LED header
N Front panel header
O Serial ATA connectors [5]
P Front panel USB header
Q Front panel USB header
R Front panel USB header
S IEEE-1394a header
T High Definition Audio Link header
