1.9 Audio Subsystem
The onboard audio subsystem consists of the following:
• Intel 82801JDO (ICH10DO)
• ADI AD1882 audio codec
• Back panel audio connectors
• Component-side audio headers:
⎯ Intel
®
High Definition Audio front panel header
⎯ HD audio link header
The audio subsystem supports the following features:
• A dynamic range of 95 dB
• 5.1 channel audio (using the back panel audio connectors)
• Independent multi-streaming stereo (using the Intel High Definition Audio front
panel header).
NOTE
Systems built with an AC 97 front panel will not be able to obtain the Microsoft
Windows Vista* logo.
Table 5 lists the supported functions of the front panel and back panel audio jacks.
Table 5. Audio Jack Retasking Support
Audio Jack
Supports
Micro-
phone?
Supports
Line out?
Supports
Head-
phones?
Supports
Line in?
Supports
Rear
Surround?
Supports
Center/
LFE?
Front panel – Green No Yes Yes No No No
Front panel – Pink Yes No No No No No
Back panel – Blue No No No Yes Yes No
Back panel – Green No Yes Yes No No No
Back panel – Pink Yes No No No No Yes
