Intel Desktop Board DQ45CB Technical Product Specification
64
Table 26 lists the recommended power supply current values.
Table 27. Recommended Power Supply Current Values
Output Voltage
3.3 V 5 V 12 V1 12 V2 -12 V 5 VSB
Current
3.71 A 7.89 A 3.03 A 8.16 A 0.05 A 1.28 A
2.5.2 Fan Header Current Capability
CAUTION
The processor fan must be connected to the processor fan header, not to a chassis fan
header. Connecting the processor fan to a chassis fan header may result in onboard
component damage that will halt fan operation.
Table 28 lists the current capability of the fan headers.
Table 28. Fan Header Current Capability
Fan Header Maximum Available Current
Processor fan 2.0 A
Front chassis fan 1.5 A
Rear chassis fan 1.5 A
