Intel Desktop Board DQ45CB Technical Product Specification
66
Figure 16 shows the locations of the localized high temperature zones.
Item Description
A Processor voltage regulator area
B Processor
C Intel 82801JDO (ICH10DO)
D Intel 82Q45 GMCH
Figure 16. Localized High Temperature Zones
Table 29 provides maximum case temperatures for the board components that are
sensitive to thermal changes. The operating temperature, current load, or operating
frequency could affect case temperatures. Maximum case temperatures are important
when considering proper airflow to cool the board.
Table 29. Thermal Considerations for Components
Component Maximum Case Temperature
Processor For processor case temperature, see processor datasheets and
processor specification updates
Intel 82Q45 GMCH 103
o
C (under bias)
Intel 82801JDO (ICH10DO) 112
o
C (under bias)
