Intel DQ45CB User Manual

9
1 Product Description
1.1 Overview
1.1.1 Feature Summary
Table 1 summarizes the major features of the Intel Desktop Board DQ45CB.
Table 1. Feature Summary
Form Factor Micro-ATX (9.60 inches by 9.60 inches [243.84 millimeters by
243.84 millimeters])
Processor Support for the following:
• Intel
®
Core™2 Quad processor in an LGA775 socket
• Intel
®
Core™2 Duo processor in an LGA775 socket
• Intel
®
Pentium
®
Dual-Core processor in an LGA775 socket
• Intel
®
Celeron
®
Dual-Core processor in an LGA775 socket
• Intel
®
Celeron
®
processor 400 Sequence in an LGA775 socket
Memory
• Four 240-pin DDR2 SDRAM Dual Inline Memory Module (DIMM) sockets
• Support for DDR2 800 MHz or DDR2 667 MHz DIMMs
• Support for up to 8 GB of system memory using DDR2 800 MHz or DDR2
667 MHz DIMMs
Chipset
Intel
®
Q45 Express Chipset, consisting of:
• Intel
®
82Q45 Graphics and Memory Controller Hub (GMCH)
• Intel
®
82801JDO I/O Controller Hub (ICH10DO)
Audio 5.1-channel audio subsystem using the ADI AD1882 high definition audio codec
Video Intel
®
Graphics Media Accelerator 4500 (Intel
®
GMA 4500) onboard graphics
subsystem
Legacy I/O Control Legacy I/O controller for serial port header
Peripheral
Interfaces
• Twelve USB 2.0 ports: six back panel connectors and six front panel headers
• Two IEEE-1394a interfaces: one back panel connector and one front-panel
header
• Six Serial ATA (3 Gbps) interfaces, including one red-colored external Serial
ATA (eSATA) interface on the back panel
• One serial port header (may require specialized chassis or cable for use)
LAN Support Gigabit (10/100/1000 Mbits/sec) LAN subsystem using the Intel
®
82567LM
Gigabit Ethernet Controller
BIOS
• Intel
®
BIOS (resident in the SPI Flash device)
• Support for Advanced Configuration and Power Interface (ACPI), Plug and Play,
and SMBIOS
continued

Intel DQ45CB Specifications

General

Brand	Intel
Model	DQ45CB
Category	Motherboard
Language	English
