Intel DQ67OW

Desktop Board Features
13
Table 2. Intel Desktop Board DQ67OW Components
Label Description
A Conventional PCI bus add-in card connector
B Front panel audio header
C PCI Express 2.0 x4 add-in card connector
D Internal mono speaker header
E PCI Express 2.0 x1 add-in card connector
F PCI Express 2.0 x16 add-in card connector
G Back panel connectors
H 12 V processor core voltage connector (2 x 2 pin)
I Processor socket
J Processor fan header
K DDR3 DIMM 3 socket
L DDR3 DIMM 1 socket
M DDR3 DIMM 4 socket
N DDR3 DIMM 2 socket
O Serial port header
P Battery
Q Chassis intrusion header
R Diskette drive connector
S Front chassis fan header
T Main power connector (2 x 12 pin)
U Standby power indicator LED
V Speaker
W Alternate front panel power LED header
X Front panel header
Y SATA connectors
Z Intel
®
Management Engine BIOS Extension (Intel
®
MEBX) reset header
AA BIOS configuration jumper block
BB Intel
®
Fast Call for Help (Intel
®
FCFH) header
CC Front panel USB 2.0 headers
DD S/PDIF header
EE Rear chassis fan header
