Installing and Replacing Desktop Board Components
59
Setting the BIOS Configuration Jumper
NOTE
Always turn off the power to the computer before moving the jumper. Moving the
jumper with the power on may result in unreliable computer operation.
Figure 26 shows the location of the Desktop Board’s BIOS confi
guration jumper block.
Figure 26. Location of the BIOS Configuration Jumper Block
