Intel Desktop Board DQ77KB Technical Product Specification
14
Table 2. Feature Summary (continued)
Peripheral
Interfaces
• Four USB 3.0 ports are implemented with stacked back panel connectors (blue,
includes two USB charging ports)
• Eight USB 2.0 ports:
― Five front panel ports implemented through three internal headers (two
dual and one single header)
― One port implemented in the PCI Express Half–Mini Card slot
― Two ports implemented in the PCI Express Full-Mini Card slot
• Five Serial ATA (SATA) ports:
― Two SATA 6.0 Gb/s interfaces through the Intel Q77 Express Chipset with
Intel
®
Rapid Storage Technology RAID support (blue)
― Two internal SATA 3.0 Gb/s interfaces through Intel Q77 Express Chipset
with Intel Rapid Storage Technology RAID support (black)
― One internal mSATA port (PCI Express Full-Mini-Card slot)
•
One serial port connector
Expansion
Capabilities
• One PCI Express 3.0 x4 add-in card connector
• One PCI Express Half-Mini Card slot
• One PCI Express Full-/Half-Mini Card slot
Note: PCI Express 3.0 is only supported by 3
rd
generation Intel Core processor
family processors
BIOS
• Intel
®
BIOS resident in the SPI Flash device
• Support for Advanced Configuration and Power Interface (ACPI), Plug and Play,
and SMBIOS
Instantly Available
PC Technology
• Support for PCI Express* Revision 3.0
• Suspend to RAM support
•
Wake on PCI Express, LAN, front panel, serial, and USB ports
LAN Support
Two Gigabit (10/100/1000 Mb/s) LAN subsystems using the Intel
®
82579LM
Gigabit Ethernet Controller (red connector) and Intel
®
82574L Gigabit Ethernet
Controller (black connector)
Legacy I/O Control Nuvoton NCT6776D I/O controller for serial port and hardware management
support
Hardware Monitor
Subsystem
• Hardware monitoring through the Nuvoton I/O controller
• Voltage sense to detect out of range power supply voltages
• Thermal sense to detect out of range thermal values
• Two fan headers
• Two fan sense inputs used to monitor fan activity
•
Fan speed control
Intel
®
Security and
Manageability
Technologies
• Intel
®
vPro™ Technology
• Intel
®
Active Management Technology (Intel
®
AMT) 8.0
• Intel
®
Small Business Technology (Intel
®
SBT)
• Intel
®
Virtualization Technology (Intel
®
VT)
• Intel
®
Virtualization for Directed I/O (Intel
®
VT-d)
•
Intel
®
Anti-Theft (Intel
®
AT)
