1.1.3 Board Layout (Bottom)
Figure 2 shows the location of the major components on the bottom-side of the Intel
Desktop Board DQ77KB.
Figure 2. Major Board Components (Bottom)
Table 4. Components Shown in Figure 2
Item/callout from
Figure 2 Description
A Embedded DisplayPort (eDP) connector
