Intel Desktop Board DQ77KB Technical Product Specification
16
Table 3 lists the components identified in Figure 1.
Table 3. Components Shown in Figure 1
Item/callout
from Figure 1 Description
A Internal stereo speakers connector
B Serial port header
C Intel Q77 Express Chipset
D Intel
®
Management Engine BIOS Extension (Intel
®
MEBX) Reset header
E BIOS Setup configuration jumper block
F Back panel connectors
G Intel
®
Management Engine “M” state LED
H Internal power connector (1 x 2 pin)
I PCI Express Full-/Half-Mini Card slot
J System fan header
K Front panel single-port USB 2.0 header
L SATA 6.0 Gb/s connectors through the PCH (blue)
M SATA 3.0 Gb/s connectors through the PCH (black)
N Front panel header
O Standby power LED
P SATA power connector
Q PANEL_OFF header
R Chassis intrusion header
S Panel voltage selection header
T LVDS connector
U DDR3 SO-DIMM 2 socket
V DDR3 SO-DIMM 1 socket
W FPD brightness connector
X Backlight inverter voltage selection header
Y Front panel dual-port USB 2.0 connector
Z Low Pin Count (LPC) Debug connector
AA Front panel dual-port USB 2.0 connector
BB Processor fan header
CC LGA1155 processor socket
DD PCI Express Half-Mini Card slot
EE PCI Express x4 add-in card connector
FF Custom Solutions header
GG Front panel audio connector
HH DMIC header
II Battery
