Intel Desktop Board DQ77MK Technical Product Specification
14
Table 1. Feature Summary (continued)
Peripheral
Interfaces
• Four USB 3.0 ports:
― Two USB 3.0 ports are implemented with stacked back panel connectors
(blue)
― Two front panel USB 3.0 ports are implemented through one internal
connector (blue)
• Ten USB 2.0 ports:
― Four ports implemented with stacked back panel connectors (two black and
two orange high current charging ports)
― Four front panel ports implemented through two internal headers (black)
― Two ports are implemented in the PCI Express Full-/Half–Mini Card slot
• Six Serial ATA (SATA) ports:
― Two SATA 6.0 Gb/s interface through the Intel Q77 Express Chipset with
Intel
®
Rapid Storage Technology RAID support (blue)
― Two internal SATA 3.0 Gb/s interfaces through Intel Q77 Express Chipset
with Intel Rapid Storage Technology RAID support (black)
― One internal SATA connector (multiplexed with an mSATA port, routed to
the PCI Express Full-/Half-Mini Card slot) (gray)
― One external eSATA 3.0 Gb/s interface (red)
• One serial port connector
• Two IEEE 1394a ports:
― One port via a back panel connector
― One port via a front-panel connector (blue)
Expansion
Capabilities
•
One PCI Express 3.0 x16 add-in card connector
• One PCI Express 2.0 x4 bus add-in card connector from the PCH
• One PCI Express 2.0 x1 bus add-in card connector from the PCH
• One Conventional PCI bus add-in card connectors from the PCH
• One PCI Express Full-/Half-Mini Card connector from the PCH (supporting
mSATA, Wireless Intel
®
Active Management Technology (Intel
®
AMT), and USB
capabilities)
Note: PCI Express 3.0 is only supported by 3
rd
generation Intel Core processor
BIOS
•
Intel
®
BIOS resident in the SPI Flash device
• Support for Advanced Configuration and Power Interface (ACPI), Plug and Play,
Instantly Available
PC Technology
• Support for PCI Express* Revision 3.0
• Suspend to RAM support
• Wake on PCI, PCI Express, LAN, front panel, serial, and USB ports
LAN Support
Two Gigabit (10/100/1000 Mb/s) LAN subsystems using the Intel
®
82579LM
Gigabit Ethernet Controller (red connector) and Intel
®
82574L Gigabit Ethernet
Controller (black connector)
Legacy I/O Control Nuvoton NCT6776D I/O controller for serial port and hardware management
Hardware Monitor
Subsystem
• Hardware monitoring through the Nuvoton I/O controller
• Voltage sense to detect out of range power supply voltages
• Thermal sense to detect out of range thermal values
• Three fan headers
• Two fan sense inputs used to monitor fan activity
Intel
®
Security and
Manageability
Technologies
• Intel
®
vPro™ Technology
• Intel
®
Active Management Technology (Intel
®
AMT) 8.0
• Intel
®
Small Business Technology (Intel
®
SBT)
• Intel
®
Virtualization Technology (Intel
®
VT)
• Intel
®
Virtualization for Directed I/O (Intel
®
VT-d)
®
®
