Intel DQ77MK User Manual

Product Description
45
1.12.2.10 +5 V Standby Power Indicator LED
The +5 V standby power indicator LED shows that power is still present even when the
computer appears to be off. Figure 8 shows the location of the standby power LED.
CAUTION
If AC power has been switched off and the standby power indicator is still lit,
disconnect the power cord before installing or removing any devices connected to the
board. Failure to do so could damage the board and any attached devices.
Figure 8. Location of the Standby Power LED

Intel DQ77MK Specifications

General

Form Factor	Micro ATX
Socket	LGA 1155
Chipset	Intel Q77
Memory Type	DDR3
Memory Slots	4
Max Memory	32 GB
PCI Express x16	1
PCI Express x16 (x4 mode)	1
PCI Express x1	1
PCI	1
SATA 6Gb/s Ports	2
SATA 3Gb/s Ports	4
mSATA	1
USB 3.0 Ports	4
USB 2.0 Ports	8
Ethernet	Intel 82579LM Gigabit Ethernet
RAID Support	RAID 0, 1, 5, 10
Memory Types	DDR3 1333/1600
Video Outputs	DisplayPort
Audio	Realtek ALC892
