Intel Desktop Board DQ77MK Technical Product Specification
32
1.9.2 LAN Subsystem Software
When Intel AMT is not configured, the LAN controllers support features of Intel
®
Advanced Network Services (Intel
®
ANS). Intel ANS is included in the LAN driver
software and contains support for teaming adapters in:
• Adapter Fault Tolerance
• Switch Fault Tolerance
• Adaptive Load Balancing for both transmit and receive
• Static Link Aggregation
• IEEE 802.3ad Dynamic Link Aggregation.
LAN software and drivers are available from Intel’s World Wide Web site.
For information about
Refer to
Obtaining LAN software and drivers http://downloadcenter.intel.com
Intel
®
Advanced Network Services and adapter teaming http://www.intel.com/support/ne
twork/sb/cs-009747.htm
1.9.3 RJ-45 LAN Connectors with Integrated LEDs
Two LEDs are built into the RJ-45 LAN connectors (shown in Figure 5).
Item Description
A Link LED (Green)
B Data Rate LED (Green/Yellow)
C Link LED (Green)
D Data Rate LED (Green/Yellow)
Figure 5. LAN Connectors LED Locations
