Product Description
25
Table 4. DVI Port Status Conditions
PCI Express x16 Connector Status
DVI Digital (DVI-D)
Port Status
DVI Analog (DVI-A)
Port Status
(Note 1)
PCI Express x16 add-in card installed
Notes:
1. DVI analog output can also be converted to VGA with a DVI-VGA converter.
2. May require BIOS setup menu changes.
1.5.2.4 DisplayPort
DisplayPort is a digital communication interface that utilizes differential signaling to
achieve a high bandwidth bus interface designed to support connections between PCs
and monitors, projectors, and TV displays. DisplayPort is suitable for display
connections between consumer electronics devices such as high definition optical disc
players, set top boxes, and TV displays. DisplayPort output can also be converted to
HDMI using a DisplayPort-HDMI converter. The DisplayPort interface supports the 1.1a
specification.
DisplayPort’s maximum supported display resolution is 2560 x 1600 at 60 Hz refresh
with a 16:10 aspect ratio (WQXGA).
Table 5. DisplayPort Status Conditions
PCI Express x16 Connector Status DisplayPort Status
PCI Express x16 add-in card installed
Note: May require BIOS setup menu changes.
For information about Refer to
DisplayPort technology http://www.displayport.org
1.5.2.5 Integrated Audio Provided by the DisplayPort Interface
The DisplayPort interface from the PCH supports audio. Table 6 shows the specific
audio technologies supported by the PCH.
Table 6. Audio Formats Supported by the DisplayPort Interface
Audio Formats DisplayPort
Dolby Digital Plus No
LPCM, 192 kHz/24 bit, 8 Channel Yes
