Intel Desktop Board DQ77MK Technical Product Specification
58
2.2.2.2 Add-in Card Connectors
The board has the following add-in card connectors:
• One PCI Express x16 (3.0/2.x/1.x)
• One PCI Express x4 (2.x/1.x)
• One PCI Express x1 (2.x/1.x)
• One Conventional PCI (rev 2.3)
Note the following considerations for the Conventional PCI bus connector:
• The Conventional PCI bus connector is bus master capable.
• SMBus signals are routed to the Conventional PCI bus connector. This enables
Conventional PCI bus add-in boards with SMBus support to access sensor data on
the desktop board. The specific SMBus signals are as follows:
The SMBus clock line is connected to pin A40.
The SMBus data line is connected to pin A41.
NOTE
PCI Express 3.0 is only supported by 3
rd
generation Intel Core processor family
processors.
