Intel Desktop Board DQ77MK Technical Product Specification
56
Table 22. PCI Express Full-/Half-Mini Card Connector (continued)
Pin Signal Name Additional Signal Name
39 +3.3 V aux (mSATA) 3.3 V
40 GND
41 +3.3 V aux (mSATA) 3.3 V
42 LED_WWAN#
43 Reserved NC (mSATA indicator)
44 LED_WLAN#
45 Reserved
(mSATA) Vendor;
(Intel AMT) C-Link_CLK*
46 LED_WPAN#
47 Reserved
(mSATA) Vendor
(Intel AMT) C-Link_DAT*
48 +1.5V
49 Reserved
(mSATA) DA/DSS
(Intel AMT) C-Link_RST*
50 GND
51 Reserved (mSATA) Presence Detection
52 +3.3 V aux
NOTE
The Intel AMT C-Link signals are routed to the PCIe full-/half-mini card connector
to support Intel AMT Wake-on-LAN for wireless cards.
Table 23. SATA Connectors
Pin
Signal Name
1 Ground
2 TXP
3 TXN
4 Ground
5 RXN
6 RXP
7 Ground
