1 Product Description
1.1 Overview
1.1.1 Feature Summary
Table 1 summarizes the major features of the board.
Table 1. Feature Summary
Form Factor
Micro-ATX (9.60 inches by 9.60 inches [243.84 millimeters by
243.84 millimeters])
Processor
• 4
generation Intel
Core™ processor with up to 95 W TDP in an LGA1150
socket
― One PCI Express* x16 graphics interface
― Integrated memory controller with dual channel DDR3 memory support
― Integrated graphics processing
― External graphics interface controller
Memory
• Four 240-pin DDR3 SDRAM Dual Inline Memory Module (DIMM) sockets
• Support for DDR3 1333 MHz to DDR3 1600 MHz DIMMs
• Support for 1 Gb, 2 Gb, and 4 Gb memory technology
• Support for up to 32 GB of system memory with four DIMMs using 4 Gb
memory technology
• Support for non-ECC memory
• Support for 1.5 V (standard voltage) and 1.35 V (low voltage) JEDEC memory
• Support for XMP memory
Chipset
Intel
Q87 Express Chipset consisting of the Intel
Q87 Express Platform
Controller Hub (PCH)
Graphics
• Integrated graphics support for processors with Intel
Graphics Technology:
― VGA
― DVI-D
― DisplayPort* v1.2
• Support for a PCI Express 3.0 x16 add-in graphics card
Audio 8-channel (6+2) Intel High Definition Audio via the Realtek* ALC662 audio codec
