Intel Desktop Board DQ87PG Technical Product Specification
70
Table 37 lists the BIOS Setup program menu features.
Table 37. Intel Visual BIOS Setup Display Areas
Home 1 Home 2 Home 3 Main
Devices &
Peripherals Cooling
Displays
processor,
graphics,
memory, and
configuration with
quick launch to
tuning, UEFI
apps, BIOS
update, and
system profiles
Environmental
monitoring
display and
attached SATA
devices
System,
desktop
board,
chassis, and
processor
information
Displays
processor,
memory,
configuration,
event log,
date, and
time
Configures
advanced
features
available
through the
chipset and
other discrete
controllers
Real-time system
monitoring,
adjust fan
speeds, set
temperature set
points, and define
system voltage
settings
continued
Table 37. Intel Visual BIOS Setup Display Areas (continued)
Performance Security Power Boot Exit
Displays and
Configures Memory,
Graphics, Bus, and
Processor overrides
Sets passwords
and security
features
Configures power
management features
and power supply
controls
Selects boot
options and
boot display
options
Saves or discards
changes to Setup
program options
Table 38 lists the function keys available for menu screens.
Table 38. BIOS Setup Program Function Keys
BIOS Setup Program
Function Key Description
<←> or <→>
Selects a different menu screen (Moves the cursor left or right)
<↑> or <↓>
Selects an item (Moves the cursor up or down)
<Tab> Selects a field (Not implemented)
Mouse Allows control of all options and slider controls in Intel Visual BIOS
<Enter> Executes command or selects the submenu
<F9> Load the default configuration values for the current menu
<F10> Save the current values and exits the BIOS Setup program
<Esc> Exits the menu
3.2 BIOS Flash Memory Organization
The Serial Peripheral Interface Flash Memory (SPI Flash) includes a 96 Mb (12288 KB)
flash memory device.
