Intel Desktop Board DQ87PG Technical Product Specification
14
Table 2 lists the components identified in Figure 1.
Table 2. Components Shown in Figure 1
Item/callout
from Figure 1 Description
A Conventional PCI add-in card connector
B Conventional PCI add-in card connector
C Rear fan header
D S/PDIF out header
E PCI Express x16 add-in card connector
F Battery
G PCI Express x1 add-in card connector
H Back panel connectors
I Piezoelectric speaker
J 12 V processor core voltage connector (2 x 2)
K LGA1150 processor socket
L Power supervisor LED
M Processor fan header
N Standby power LED
O DIMM 3 (Channel A DIMM 0)
P DIMM 1 (Channel A DIMM 1)
Q DIMM 4 (Channel B DIMM 0)
R DIMM 2 (Channel B DIMM 1)
S Front fan header
T Main power connector (2 x 12)
U Front panel USB 3.0 connector
V Intel
®
Management Engine “M” state LED
W Intel Q87 Express Chipset
X Intel
®
Management Engine BIOS Extension (Intel
®
MEBX) Reset header
Y Chassis intrusion header
Z Alternate front panel power/sleep LED header
AA Front panel connector
BB SATA 6.0 Gb/s connectors
CC BIOS Setup configuration jumper block
DD Front panel USB 2.0 connector
EE Front panel USB 2.0 connector
FF Front panel USB 2.0 connector
GG Serial port connector
HH Front panel audio connector
II Internal mono speaker header

Intel DQ87PG Specifications

General

Brand	Intel
Model	DQ87PG
Category	Motherboard
Language	English
