Table 12 lists the component-side connectors and headers identified in Figure 10.
Table 12. Component-side Connectors and Headers Shown in Figure 10
Item/callout f
rom Figure 10 Description
A Conventional PCI add-in card connector
B Conventional PCI add-in card connector
C Rear fan header
D S/PDIF out header
E PCI Express x16 add-in card connector
F PCI Express x1 add-in card connector
G 12 V processor core voltage connector (2 X 2)
H Processor fan header
I Front chassis fan header
J Main power connector (2 x 12)
K Front panel USB 3.0 connector
L Chassis intrusion header
M Alternate front panel power/sleep LED header
N Front panel connector
O SATA 6.0 Gb/s connectors
P Front panel USB 2.0 connector
Q Front panel USB 2.0 connector
R Front panel USB 2.0 connector
S Serial port connector
T Front panel audio connector
U Internal mono speaker header
