Intel Desktop Board DX58SO2 Technical Product Specification
12
Table 2. Components Shown in Figure 1
Item/callout
from Figure 1
Descript
ion
A Front panel audio header
B PCI Express x1 connector
C S/PDIF out header
D PCI Express x16 bus connector
E Conventional PCI bus add-in card connector
F PCI Express x16 bus add-in card connector (Secondary)
G PCI Express x1 bus add-in card connector
H PCI Express x16 bus add-in card connector (Primary)
I Rear chassis fan header
J Intel 82X58 IO Hub (IOH)
K Back panel connectors
L Processor fan header
M Processor core power connector (2 x 4)
N LGA1366 processor socket
O DIMM 4 socket
P DIMM 1 socket
Q DIMM 5 socket
R DIMM 2 socket
S DIMM 6 socket
T DIMM 3 socket
U Main power connector (2 x 12)
V Front chassis fan header
W Intel 82801IJR I/O Controller Hub (ICH10R)
X SATA connectors (six 3 Gb/s interfaces (black) and two 6 Gb/s interfaces (blue))
Y Chassis intrusion header
Z Piezoelectric speaker
AA Front panel USB headers (3)
BB Consumer IR receiver (input) header
CC Consumer IR emitter (output) header
DD BIOS Setup configuration jumper block
EE Front panel header
FF Auxiliary front panel power LED header
GG Post Code LED display
HH IEEE 1394a front panel header
II Battery
JJ Onboard Reset button
KK Onboard Power button
LL Base Clock Frequency Increase button
MM Base Clock Frequency Decrease button
NN Auxilliary chassis fan header
OO Status LEDs
