Intel Desktop Board DX58SO2 Technical Product Specification

Table 14. Chassis Intrusion Header

Pin Signal Name

1 Intruder

2 Ground

Table 15. Front and Rear Chassis (3-Pin) Fan Headers

Pin Signal Name

1 Control

(Note)

2 +12 V

3 Tach

Note: These fan headers use voltage variance control for fan speed.

Table 16. Processor and Rear Chassis 2 (4-Pin) Fan Headers

Pin Signal Name

1 Ground

(Note)

2 +12 V

3 FAN_TACH

4 FAN_CONTROL

Note: These fan headers use Pulse Width Modulation control for fan speed.

Table 20. Back Panel CIR Emitter (Output) Header

Pin Signal Name

1 Emitter out 1

2 Emitter out 2

3 Ground

4 Key (no pin)

5 Jack detect 1

6 Jack detect 2

Table 21. Front Panel CIR Receiver (Input) Header

Pin Signal Name

1 Ground

2 LED

3 NC

4 Learn-in

5 5 V standby

6 VCC

7 Key (no pin)

8 CIR Input
