Intel Desktop Board DX58SO2 Technical Product Specification
24
1.11 LAN Subsystem
The Intel GbE Dual LAN subsystem consists of the following:
• Intel 82567L and Intel 82574L Gigabit Ethernet Controllers
(10/100/1000 Mbits/sec)
• Intel 82801IJR (ICH10R)
• RJ-45 LAN connector with integrated status LEDs
Additional features of the LAN subsystem include:
• CSMA/CD protocol engine
• LAN connect interface between ICH10R and the LAN controller
• Conventional PCI bus power management
⎯ ACPI technology support
⎯ LAN wake capabilities
• LAN subsystem software
For information about Refer to
LAN software and drivers http://downloadcenter.intel.com
1.11.1 Intel
®
82567L and Intel
®
82574L Gigabit Ethernet
Controllers
The Intel 82567L and Intel
®
82574L Gigabit Ethernet Controllers support the following
features:
• PCI Express link
• 10/100/1000 IEEE 802.3 compliant
• Compliant to IEEE 802.3x flow control support
• 802.1p and 802.1q
• TCP, IP, and UDP checksum offload (for IPv4 and IPv6)
• Transmit TCP segmentation
• Full device driver compatibility
• PCI Express power management support
