Intel Desktop Board DX58SO2 Technical Product Specification
44
Table 10 lists the component-side connectors and headers identified in Figure 11.
Table 10. Component-side Connectors and Headers Shown in Figure 11
Item/callout
from Figure 11 Descript
ion
A Front panel audio header
B PCI Express x1 connector
C S/PDIF out header
D PCI Express x16 bus connector
E Conventional PCI bus add-in card connector
F PCI Express x16 bus add-in card connector (Secondary)
G PCI Express x1 bus add-in card connector
H PCI Express x16 bus add-in card connector (Primary)
I Rear chassis fan header
J Processor fan header
K Processor core power connector (2 x 4)
L Main power connector (2 x 12)
M Front chassis fan header
N SATA connectors (six 3 Gb/s interfaces (black) and two 6 Gb/s interfaces (blue))
O Chassis intrusion header
P Front panel USB header
Q Front panel USB header
R Front panel USB header
S Consumer IR receiver (input) header
T Consumer IR emitter (output) header
U Front panel header
V Auxiliary front panel power LED header
W IEEE 1394a front panel header
X Auxiliary chassis fan header

Intel DX58SO2 Specifications

General

Brand	Intel
Model	DX58SO2
Category	Motherboard
Language	English
