Intel Desktop Board DZ87KLT-75K Technical Product Specification
12
Table 1. Feature Summary (continued)
Peripheral
Interfaces
• USB 3.0 ports:
― Six ports implemented with stacked back panel connectors (blue)
― Two ports implemented through one dual-port internal connector (blue)
• USB 2.0 ports:
― Two ports implemented with stacked back panel connectors (orange high
current charging ports)
― Six front panel ports are implemented through three dual-port internal
connectors (two black and one orange high current charging port)
• Serial ATA (SATA) ports:
― Six SATA 6.0 Gb/s interfaces through the Intel Z87 Express Chipset with
Intel
®
Rapid Storage Technology RAID support (blue)
― Two SATA 6.0 Gb/s interfaces through a Marvel 88SE9172 controller
(gray)
• Two IEEE 1394a ports:
― One port via a back panel connector
― One port via a front-panel connector (blue)
Wireless Module
•
Separate module that provides both Bluetooth* and WiFi included with the
desktop board
Note: Only Bluethooth v2.1 is supported
Intel
®
Visual BIOS
•
Intel
®
BIOS resident in SPI Flash device
• Support for Advanced Configuration and Power Interface (ACPI), Plug and
Play, and SMBIOS
Instantly Available
PC Technology
• Support for PCI* Local Bus Specification Revision 2.2
• Support for PCI Express* Revision 2.0
• Suspend to RAM support
• Wake on PCI, PCI Express, LAN, front panel, CIR, and USB ports
Connectivity
• Two Gigabit (10/100/1000 Mb/s) LAN subsystems using the Intel
i217V
Gigabit Ethernet Controller and Intel
®
i210 Gigabit Ethernet Controller
• Thunderbolt™ Technology Interface
Expansion
Capabilities
• Three PCI Express 3.0 x16 bus add-in card connectors from the processor
― 1
st
PCI Express x16 slot is electricallyx8 or x16
― 2
nd
PCI Express x16 slot is electrically x8 or disabled
― 3
rd
PCI Express x16 slot is electrically x4
• Three PCI Express 2.0 x1 bus add-in card connectors from the PCH
• One Conventional PCI bus add-in card connector from the PCH via a PCI
bridge
• One PCI Express Full-/Half-Mini Card slot with support for mSATA
Note: No USB is routed to the PCI Express Full-/Half-Mini Card slot
Hardware Monitor
Subsystem
•
Hardware monitoring and fan control through the Nuvoton I/O controller
• Voltage sense to detect out of range power supply voltages
• Thermal sense to detect out of range thermal values
• Six fan headers using PWM control
• Fan sense inputs used to monitor fan activity
• Fan speed control using voltage control (4-pin fan headers front, rear, and
auxiliary) with selectable support in BIOS for 3-wire fans
• Support for Platform Environmental Control Interface (PECI)
