Intel Desktop Board DZ87KLT-75K Technical Product Specification
14
Table 2. Components Shown in Figure 1
Label Description
A PCI Express x16 add-in card connector (x4 electrical; x16 compatible)
B Conventional PCI add-in card connector
C PCI Express x16 add-in card connector (x8 electrical; x16 compatible)
D PCI Express x1 add-in card connector
E PCI Express x1 add-in card connector
F PCI Express x16 add-in card connector
G Battery
H Rear chassis fan header 2
I PCI Express x1 add-in card connector
J Rear chassis fan header 1
K Back panel connectors
L 12 V processor core voltage connector (2 x 4 pin)
M LGA 1150 processor socket
N Voltage regulator status LEDs
O Processor fan header
P DIMM 3 (Channel A DIMM 0)
Q DIMM 1 (Channel A DIMM 1)
R DIMM 4 (Channel B DIMM 0)
S DIMM 2 (Channel B DIMM 1)
T Front chassis fan header 1
U Front chassis fan header 2
V Onboard power button
W Onboard reset button
X Piezoelectric speaker
Y Main power connector (2 x 12)
Z Standby power LED
AA Front panel USB 3.0 connector
BB BIOS security jumper
CC Chassis intrusion header
DD SATA 6.0 Gb/s connectors through the PCH (blue)
EE SATA 6.0 Gb/s connectors through a Marvel 88SE9172 controller (gray)
FF PCI Express Full-/Half-Mini Card slot
GG Consumer IR receiver (input) header
HH Alternate front panel power/sleep LED header
II Front panel connector
JJ Power On Self Test (POST) LED display
KK POST LED display
LL Front panel USB 2.0 connector (black)
continued
