Intel Desktop Board DZ87KLT-75K Technical Product Specification
26
1.5.3 SATA Interfaces
The board provides eight SATA connectors, through the PCH, which support one device
each:
• Six SATA 6.0 Gb/s interfaces through the Intel Z87 Express Chipset with Intel
®
Rapid Storage Technology RAID support (blue)
• Two SATA 6.0 Gb/s interfaces through a Marvel 88SE9172 controller (gray)
The PCH provides independent SATA ports with a theoretical maximum transfer rate of
6.0 Gb/s. A point-to-point interface is used for host to device connections.
The PCH supports the Serial ATA Specification, Revision 3.0. The PCH also supports
several optional sections of the Serial ATA II: Extensions to Serial ATA 1.0
Specification, Revision 1.0 (AHCI support is required for some elements).
NOTE
Many SATA drives use new low-voltage power connectors and require adapters or
power supplies equipped with low-voltage power connectors.
For more information, see: http://www.serialata.org/
.
For information about Refer to
The location of the SATA connectors Figure 13, page 52
1.5.3.1 Intel
®
Rapid Storage Technology/SATA RAID
The PCH supports Intel
®
Rapid Storage Technology, providing both AHCI and
integrated RAID functionality. The RAID capability provides high-performance RAID 0,
1, 5, and 10 functionality on all SATA ports. Other RAID features include hot spare
support, SMART alerting, and RAID 0 auto replace. Software components include an
Option ROM for pre-boot configuration and boot functionality, a Microsoft* Windows*
compatible driver, and a user interface for configuration and management of the RAID
capability of the PCH.
1.5.3.2 Intel
®
Smart Response Technology
Intel
®
Smart Response Technology is a disk caching solution that can provide improved
computer system performance with improved power savings. It allows configuration of a
computer system with the advantage of having HDDs for maximum storage capacity
with system performance at or near SSD performance levels.
For more information on Intel Smart Response Technology, go to
http://www.intel.com/support/chipsets/sb/CS-032826.htm
NOTE
In order to use supported RAID and Intel Smart Response Technology features, you
must first enable RAID in the BIOS.
