Technical Reference
67
2.5.2 Fan Header Current Capability
CAUTION
The processor fan must be connected to the processor fan header, not to a chassis fan
header. Connecting the processor fan to a chassis fan header may result in onboard
component damage that will halt fan operation.
Table 32 lists the current capability of the fan headers.
Table 32. Fan Header Current Capability
Fan Header Maximum Available Current
Processor fan 2.0 A
Front chassis fans 1.5 A
Rear chassis fans 1.5 A
Auxiliary chassis fan 1.5 A
2.5.3 Add-in Board Considerations
The board is designed to provide 2 A (average) of current for each add-in board from
the +5 V rail. The total +5 V current draw for add-in boards for a fully loaded board
(all six expansion slots filled) must not exceed the system’s power supply +5 V
maximum current or 14 A in total.
