Intel Desktop Board DZ87KLT-75K Technical Product Specification
72
Figure 20. Intel Visual BIOS Screen
Table 35 lists the BIOS Setup program menu features.
Table 35. Intel Visual BIOS Setup Display Areas
Home 1
Home 2
Home 3
Main
Devices &
Peripherals
Cooling
Displays
processor,
graphics,
memory, and
configuration with
quick launch to
tuning, UEFI
apps, BIOS
update, and
system profiles
Environmental
monitoring
display and
attached SATA
devices
System,
desktop
board,
chassis, and
processor
information
Displays
processor,
memory,
configuration,
event log,
date, and
time
Configures
advanced
features
available
through the
chipset and
other discrete
controllers
Real-time system
monitoring, adjust
fan speeds, set
temperature set
points, and define
system voltage
settings
continued
