Intel Edison User Manual

Digikey sources
4 Digikey sources
Figure 7 shows some third-party accessories you can use.
Figure 7 Digikey sources
Mating connector 2.0 mm
DF40C(2.0)-70DS-0.4V(51) - H11908CT-ND
Cut tape
DF40C(2.0)-70DS-0.4V(51) H11908TR-ND Tape and reel
Mini-breakout power jack PJ-002BH-SMT-TR
CP-002BHPJCT-ND Cut tape
PJ-002BH-SMT-TR CP-002BHPJTR-ND
Tape and reel
Mini-breakout USB adapter cable
USB A female to Micro A male 10-00649 839-1105-ND
Mini-breakout male header
2x14 M20-9980745 952-1932-ND
§
Intel® Edison Breakout Board
Hardware Guide January 2015
14 Document Number: 331190-006

Intel Edison Specifications

General

RAM	1 GB LPDDR3
Flash Memory	4 GB eMMC
Wi-Fi	802.11a/b/g/n
Bluetooth	Bluetooth 4.0
USB	USB 2.0 OTG
Dimensions	35.5 mm x 25.0 mm x 3.9 mm
Operating System	Yocto Linux
GPIO	40
Power Supply	3.3V - 4.5V
CPU	Dual-core Intel Atom Silvermont, 500 MHz
