Intel H310

10
Pin 3&4 of JBAT (6-pin): Flash Descriptor Override Select
Pin1
2
Pin1
2
Pin 3&4 of JBAT →
Flash Descriptor Override
3-4 Open: Normal(Default);
3
4
3-4 Closed: Disable Flash
Descriptor Security (override).
3
4
Pin 5&6 of JBAT (6-pin): PWROK Override Select
Pin1
2
Pin1
2
5-6 Open: Normal(Default);
3
4
3
4
Pin 5&6 of JBAT → PWROK Override
5-6 Closed: PWROK Override.
6
5
5
6
* Note: PWROK override is for manufacturing test only.
JBAT
JBAT
