Intel H310 User Manual

35
The optional settings: [1]; [2].
Flow Control
Flow control can prevent data loss from buffer overflow. When sending data, if
the receiving buffers are full, a “stop” signal can be sent to stop the data flow.
Once the buffers are empty, a “start” signal can be sent to re-start the flow.
Hardware flow control uses two wires to send start/stop signals.
The optional settings: [None]; [Hardware RTS/CTS].
VT-UTF8 Combo Key Support
Use this item to enable VT-UTF8 Combination Key Support for ANSI/VT100
terminals.
The optional settings: [Disabled]; [Enabled].
Recorder Mode
With this mode enable only text will be sent. This is to capture Terminal data.
The optional settings: [Disabled]; [Enabled].
Resolution 100x31
Use this item to enable or disable extended terminal resolution.
The optional settings: [Disabled]; [Enabled].
Putty KeyPad
Use this item to select FunctionKey and KeyPad on Putty.
The optional settings: [VT100]; [Linux]; [XTERMR6]; [SCO]; [ESCN]; [VT400].
Legacy Console Redirection
4 Legacy Console Redirection Settings
Press [Enter] to make settings for the following item:
Legacy Console Redirection Settings
Redirection COM Port
For user to select a COM port to display redirection of legacy OS and Legacy
OPROM messages.
The optional settings are: [COM1]; [COM1(Pci Bus0, Dev0, Func0) (Disabled)].
Resolution
This item is for user to select the number of Rows and Columns supported
redirection.
The optional settings are: [80x24]; [80x25].

Intel H310 Specifications

General

Chipset	Intel H310
Socket	LGA 1151
Memory Type	DDR4
Max Memory	32 GB
PCI Express Revision	3.0
SATA Ports	4
Memory Slots	2
PCIe 3.0 x16 Slots	1
PCIe Lanes	6
RAID Support	No
Form Factor	ATX, Micro-ATX, Mini-ITX
USB 3.1 Gen 1 Ports	Up to 4
USB 2.0 Ports	Up to 6
M.2 Slots	1
Integrated Graphics	Yes (CPU Dependent)
LAN Speed	1 Gbps
USB Ports	Up to 10 (depends on implementation)
