Intel® Server Board S1200BT TPS Connector/Header Locations and Pin-outs
Revision 1.0
Intel order number G13326-003
91
Table 18. Board Connector Matrix on S1200BTS
Connector
Quantity
Reference Designators
Connector Type
Pin Count
Power supply
2
J9G1, J9A1
Main power
CPU power
24
8
CPU
1
J5J1
CPU sockets
1155
Main memory
4
J8H1, J8H2, J8H3, J9H1
DIMM sockets
240
CPU Fan
1
J4J1
Header
4
System Fans
3
J2J3, J7J1, J7B1
Header
4
Battery
1
BT2E1
Battery holder
3
NIC/Stack 2x USB
2
JA4A1, JA5A1
Dual USB
8
Video
1
J6A1
External DSub
15
Serial port A
1
J8A1
Connector
9
Front panel
1
J1C2
Header
24
USB Internal
Header
1
J1E1
Header
10
PCI-E x16
1
J4B1
Card Edge
164
PCI-E x8
2
J2B1, J3B1
Card Edge
98
PCI 32
1
J1B1
Card Edge
120
Chassis Intrusion
1
J3G1
Header
2
3Gb/s Serial ATA
6
J1J1, J1J2, J1J3, J1J4, J1H1, J1H2
Header
7
SATA RAID key
1
J3A1
Header
4
SATA_SGPIO
1
J1J2
Header
4
7.2 Power Connectors
The main power supply connection uses an SSI-compliant 2x12 pin connector (J9G1). In
addition, there is one additional power related connector:
 One SSI-compliant 2x4 pin power connector (J9G1), which provides 12-V power to the
CPU VRD.
The following tables define the connector pin-outs:
Table 19. Baseboard Power Connector Pin-out (J9G1)
Pin
Signal
Pin
Signal
1
+3.3 Vdc
13
+3.3 Vdc
2
+3.3 Vdc
14
-12 Vdc
3
GND
15
GND
4
+5 Vdc
16
PS_ON#
5
GND
17
GND
6
+5 Vdc
18
GND
7
GND
19
GND
8
PWRGD_P
S
20
NC
9
5 VSB
21
+5 Vdc
10
+12 Vdc
22
+5 Vdc
