Intel S2600CW Spares/Accessories List And Configuration Guide

Intel® Server S2600CW Product Family Configuration Guide and Spares/Accessories List
6
1.1 Product Family Summary Chart
The Intel® Server Board S2600CW product family consist in four Intel® Server Board options: DBS2600CW2R, DBS2600TR, DBS2600CW2SR, and
DBS2600CWTSR. See Table 2 for the feature set summary of each server board option.
The S2600CW2R SKU offers dual 1GbE NIC ports.
The S2600CWTR SKU offers dual 10GbE NIC ports.
The S2600CW2SR SKU offers dual 1GbE NIC ports and onboard SAS controller.
The S2600CWTSR SKU offers dual 10GbE NIC ports and onboard SAS controller.
The following tables provide an overview of the available Intel product codes for building blocks within the Intel® Server Board S2600CW product family. Each
line item identifies key features supported in the shipping Intel SKU. Additional order code information and full product descriptions for each option are
provided in later sections.
Table 2. Server Board Product Family Summary
Intel Product Code
# of CPU
sockets
# of DIMM
Slots
# of Add- in
Cards Slots
Onboard
RJ45 LAN
Ports
Onboard
SAS
Controller
Server Board only
S2600CW2R
2
16
6
2x1GbE
NA
S2600CWTR
2
16
6
2x10GbE
NA
S2600CW2SR
2
16
6
2x1GbE
Yes
S2600CWTSR
2
16
6
2x10GbE
Yes
Table 3. Server Chassis & Server System Product Family Summary
Intel Product Code
Chassis Form
Factor
Fans Bezel
Power Supply
Modules
Air
Duct
Chassis Only
P4304XXMFEN2 4U 2 x fixed
Fixed drive
bezel
Yes
1 x Fixed 550W
Yes
P4304XXMUXX 4U 5 x hot-swap
Hot-swap
drive bezel
Opt
Supports up to 2x
hot-swap 750W or
1600W
Yes
Terms used in the table:
NA – Not Applicable
Opt – Not Included - Accessory option sold separately
Yes – Option included
